Parent Layer: Fittings

Name: Water Fitting Label

Display Field: ASBLT

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description:

Service Item Id: df4f9e6e5ae04ba09812b924e3904139

Copyright Text:

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 10000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -122328300
YMin: -93908400
XMax: 737809.6909999996
YMax: 705641.3310000002
Spatial Reference: 102651  (3433)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [255, 255, 0, 0]
Size: 3.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 0] Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerPointLabelPlacementAboveRight
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [78, 78, 78, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 8
Font Family: Verdana
Font Style: normal
Font Weight: bold
Font Decoration: none

Min. Scale: 1700.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• DOCUMENTS ( type: esriFieldTypeString, alias: Documents, length: 4000 )
• STAT_TY ( type: esriFieldTypeString, alias: Status, length: 25 , Coded Values: [Operational: Operational] , [Out of Service: Out of Service] , [Under Construction: Under Construction] )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• ASBLT ( type: esriFieldTypeString, alias: As-Built #, length: 10 )
• DIAMETER1 ( type: esriFieldTypeDouble, alias: Diameter 1 (in) )
• DIAMETER2 ( type: esriFieldTypeDouble, alias: Diameter 2 (in) )
• DIAMETER3 ( type: esriFieldTypeDouble, alias: Diameter 3 (in) )
• DIAMETER4 ( type: esriFieldTypeDouble, alias: Diameter 4 (in) )
• NOTES ( type: esriFieldTypeString, alias: Notes, length: 255 )
• GPS_DATE ( type: esriFieldTypeDate, alias: GPS Date, length: 8 )
• INSTDATE ( type: esriFieldTypeDate, alias: Install Date, length: 8 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• FACILITYID ( type: esriFieldTypeString, alias: Facility ID, length: 30 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• WND_ID ( type: esriFieldTypeInteger, alias: Node Rec # )
• ND_TYPE_TY ( type: esriFieldTypeString, alias: Type, length: 25 , Coded Values: [Bend: Bend] , [Cap: Cap] , [Cleanout: Cleanout] , ...15 more... )
• W_OWNER ( type: esriFieldTypeString, alias: Owned By, length: 30 , Coded Values: [Fayetteville: Fayetteville] , [Private: Private] , [University of Arkansas: University of Arkansas] , ...3 more... )
• ADR_MUNI ( type: esriFieldTypeString, alias: Municipality, length: 20 , Coded Values: [ELKINS: ELKINS] , [ELM SPRINGS: ELM SPRINGS] , [FARMINGTON: FARMINGTON] , ...9 more... )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
