Name: Stormwater Conduit

Display Field: FACILITYID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: Each polyline feature represents a stormwater conduit such as a pipe, open channel, or stream.

Service Item Id: 887efdd6975b41ed9fb9655f74c5b961

Copyright Text: City of Fayetteville, AR

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 613547.608267054
YMin: 596278.6034537256
XMax: 732961.8326927274
YMax: 675087.663354978
Spatial Reference: 102651  (3433)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: CN_TYPE_CD
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 1
  Label: Artificial Path
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [68, 101, 137, 102]
  Width: 2
• Value: 2
  Label: Channel
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [68, 101, 137, 255]
  Width: 2
• Value: 3
  Label: Logical Connector
  Description: N/A
  Symbol:
  Style: esriSLSDash
  Color: [117, 184, 204, 255]
  Width: 1
• Value: 4
  Label: Pipe
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 170, 0, 255]
  Width: 2
• Value: 5
  Label: Stream
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [68, 101, 137, 255]
  Width: 2
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• FACILITYID ( type: esriFieldTypeString, alias: Facility ID, length: 61 )
• CN_TYPE_CD ( type: esriFieldTypeSmallInteger, alias: Type )
• AsBuiltShape ( type: esriFieldTypeString, alias: As-Built Shape, length: 1 )
• CN_DIA ( type: esriFieldTypeSmallInteger, alias: Diameter/Height (in) )
• CN_WIDTH ( type: esriFieldTypeSmallInteger, alias: Width (in) )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Length (ft) )
• CN_MATR_TY ( type: esriFieldTypeString, alias: Material, length: 40 )
• OWNER ( type: esriFieldTypeString, alias: Owned By, length: 50 )
• Shape ( type: esriFieldTypeGeometry, alias: SHAPE )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
